PCB Design

Do you have a product idea or do you want to add new features to your existing product? The heart of electronic products is the PCB (Printed Circuit Board), also known as the printed circuit board. We have experience in the smart design and production of PCBs, from idea to end product.

Read more
Pattern SST

PCB (printed circuit board) design

The functions of an electronic product are controlled from the printed circuit board. Designing, developing and ultimately producing a PCB is an intensive process and requires a structured approach. Within SST Hardware we have experts who can focus exclusively on the PCB design. This can involve designing, expanding and improving a PCB.

PCB design

PCB design software

We have extensive experience designing PCBs using all of the industry’s most popular design software. Whether it’s Altium Designer, Eagle, KiCad, or OrCAD, our experts are well-versed in these platforms and can turn complex designs into reality quickly and efficiently.

We understand that every project has unique requirements, which is why we use the software that best suits our customers’ specifications and goals. Our team ensures that every design meets the highest quality standards, regardless of the software used, so you can always count on reliable and accurate PCBs.

Please contact us

PCB Production

In addition to designing, we are also able to produce the most complex PCBs. From prototypes and pilot series to series production. Completely in-house, in the Netherlands. So we also produce PCBs that we have not designed, and vice versa, you can have a printed circuit board that we have designed produced elsewhere; no problem!

Read more about PCB production

IP & Ownership

Everything we develop for your printed circuit board is your property. The entire IP, drawings and other documentation. We also record this. During the development process, we will always share the documentation and designs in the meantime, as well as a final delivery. This way you can be sure that you are in possession of both the IP and all the necessary documentation, even if we do not continue together. How transparent!

Please contact us

FAQ

What is a PCB?

A PCB (Printed Circuit Board) is a board that supports electrical connections and components for electronic devices. It is used to physically attach and electrically connect the components.

What software is used for PCB design?

Popular PCB design software includes Altium Designer, Eagle, KiCad, and OrCAD. The choice of software depends on the complexity of the design and the specific needs of the project.

What are the main steps in PCB design?

The main steps are creating a schematic, designing the layout, placing the components, routing the traces, and checking the design with Design Rule Checks (DRC).

How long does it take to complete a PCB design?

The time to complete a PCB design varies depending on the complexity, but it can range from a few days for simple designs to a few weeks for complex, multi-layer designs.

How much does PCB design cost?

The cost of PCB design can vary greatly depending on the complexity, number of layers, components used, and manufacturing method. It is important to consult with a designer to get an accurate estimate.

What is Design for Manufacturability (DFM) in PCB design?

DFM refers to the process of designing PCBs with manufacturing requirements in mind, to ensure efficient, cost-effective, and defect-free production.

How are PCB designs tested for reliability?

PCB designs are tested using methods such as simulation, prototype testing, and the use of Design Rule Checks (DRC) to ensure electrical and mechanical reliability.
